10 PCS 10GBASE-T SFP+ Transceiver, Multi-Rate 2.5/5/10G SFP+ to RJ45 Copper Module Compatible with Cisco SFP-10G-T-S, Ubiquiti UniFi UF-RJ45-10G, Meraki, MikroTik S+RJ10, Netgear, D-Link etc.
Product details
| Management number | 209084242 | Release Date | 2026/03/29 | List Price | $91.16 | Model Number | 209084242 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
10Gb SFP+ RJ45, 30m 𝗗𝗲𝘀𝗰𝗿𝗶𝗽𝘁𝗶𝗼𝗻: ● ASF-10G-T-RTL8261 Copper Small Form Pluggable (SFP) transceivers are based on the SFP Multi Source Agreement (MSA) . ● They are compatible with the 10Gbase-T /5Gbase-T /2.5Gbase-T standards as specified in IEEE Std 802.3 . ● ASF-10G-T-RTL8261 uses the SFP's RX_LOS(must be pulled up on host) pin for link indication. If pull up or open SFP's TX_DISABLE pin, PHY IC be reset. 𝗣𝗿𝗼𝗱𝘂𝗰𝘁 𝗙𝗲𝗮𝘁𝘂𝗿𝗲𝘀 ● Support 10Gbase-T / 5Gbase-T / 2.5Gbase-T on line port ● Support 10Gbase-R on host port ● Hot-pluggable SFP footprint ● Compact RJ-45 connector assembly ● RoHS compliant and lead-free ● Single +3.3V power supply ● 10 Gigabit Ethernet over Cat 6a cable ● Ambient Operating temperature: 0°C to +70°C +𝟯.𝟯𝗩 𝗩𝗼𝗹𝘁 𝗘𝗹𝗲𝗰𝘁𝗿𝗶𝗰𝗮𝗹 𝗣𝗼𝘄𝗲𝗿 𝗜𝗻𝘁𝗲𝗿𝗳𝗮𝗰𝗲 ● The ASF-10G-T-RTL8261 has an input voltage range of +3.3V +/- 5%. The 4V maximum voltage is not allowed for continuous operation. 𝗟𝗼𝘄-𝗦𝗽𝗲𝗲𝗱 𝗦𝗶𝗴𝗻𝗮𝗹𝘀 ● MOD_DEF(1) (SCL) and MOD_DEF(2) (SDA), are open drain CMOS signals (see section VII, "Serial Communication Protocol"). Both MOD_DEF(1) and MOD_DEF(2) must be pulled up to host_Vcc. 𝗛𝗶𝗴𝗵-𝗦𝗽𝗲𝗲𝗱 𝗘𝗹𝗲𝗰𝘁𝗿𝗶𝗰𝗮𝗹 𝗜𝗻𝘁𝗲𝗿𝗳𝗮𝗰𝗲 ● All high-speed signals are AC-coupled internally. 𝗘𝗻𝘃𝗶𝗿𝗼𝗻𝗺𝗲𝗻𝘁𝗮𝗹 𝗦𝗽𝗲𝗰𝗶𝗳𝗶𝗰𝗮𝘁𝗶𝗼𝗻𝘀 ● Automatic crossover detection is enabled. External crossover cable is not required. 𝗦𝗲𝗿𝗶𝗮𝗹 𝗖𝗼𝗺𝗺𝘂𝗻𝗶𝗰𝗮𝘁𝗶𝗼𝗻 𝗣𝗿𝗼𝘁𝗼𝗰𝗼𝗹 ● All WINTOP SFPs support the 2-wire serial communication protocol outlined in the SFP MSA. These SFPs use an MCU, can be accessed with address of A0h.
- 𝐃𝐚𝐭𝐚 𝐑𝐚𝐭𝐞: Multi-rate, support 2.5Gb/5Gb/10Gb/s rate. Please note, Do Not support 1.25Gb/s rate.
- 𝐈𝐧𝐭𝐞𝐫𝐟𝐚𝐜𝐞: RJ45 connector, compact RJ-45 connector assembly. Cable Type: Cat6a/Cat7/Cat8 cables, up to 30-meter.
- 𝐅𝐞𝐚𝐭𝐮𝐫𝐞: Support Hot-pluggable. Performance Enhancement. Plug and play,hot-pluggable SFP footprint. Power Consumption ≤3W. Single +3.3V power supply. Temperature: 0℃ to 70℃. 𝐀𝐓𝐓𝐀𝐂𝐓𝐈𝐎𝐍: DO NOT TOUCH IN OPERATION DUE TO HIGH TEMPERTURE.
- 𝐖𝐢𝐝𝐞 𝐂𝐨𝐦𝐩𝐚𝐭𝐢𝐛𝐢𝐥𝐢𝐭𝐲: Compatible with Cisco SFP-10G-T-S, Ubiquiti UniFi UF-RJ45-10G, Meraki MA-SFP-10GB-T, Mikrotik S+RJ10, TP-Link TL-SM5310-T, Netgear AXM765, Cumulus, D-Link, Acction, Edgecor, F5, Linkysys, Supermicro, Zyxel and other open transceivers and switches with 10G SFP+ port.
- 𝐀𝐟𝐭𝐞𝐫-𝐬𝐚𝐥𝐞𝐬 𝐒𝐞𝐫𝐯𝐢𝐜𝐞: 30-day free returns and exchanged, 3-year warranty, and free lifetime technical support ensure worry-free use of our products.
| Color | Silver |
|---|---|
| Model | ASF-10G-T-CSC-AL(10PCS) |
| Brand Name | Alwong |
| Manufacturer | Alwong |
| Connector Type | RJ45 |
| Number of Items | 10 |
| Specification Met | Rj-45 |
| Compatible Devices | Cisco SFP-10G-T; Ubiquiti UACC-CM-RJ45-MG |
| Data Transfer Rate | 10 Gigabytes Per Second |
| Warranty Description | 3 Year |
